Cincon EC6C06 절연 DC-DC 컨버터, 25~30 와트, 2:1 입력 범위, 9-18VDC 입력, +/-15VDC 출력

Width: 50.8 mm (2 in)

Height: 10.2 mm (0.402 in)

Length: 50.8 mm (2 in)

Dimensions: 50.8 mm x 50.8 mm x 10.2 mm

Efficiency: 87 %

Unit Weight: 65 g

Output Power: 30 W

Input Voltage: 9 V to 18 V

Cooling Method: Convection

Mounting Style: Through Hole

Mechanical Style: Isolated

Isolation Voltage: 500 V

Number of Outputs: 2 Output

Input Voltage - Max: 18 V

Input Voltage - Min: 9 V

Input Voltage, Nominal: 12 V

Output Current-Channel 1: 1 A

Output Current-Channel 2: 1 A

Output Voltage-Channel 1: 15 V

Output Voltage-Channel 2: - 15 V

Maximum Operating Temperature: + 71 C

Minimum Operating Temperature: - 25 C
