Pitch: 0.375 in
Width: 0.88 in
Height: 0.41 in
Length: 2.9 in
Unit Weight: 453.592 mg
Current Rating: 30 A
Mounting Angle: Straight
Mounting Style: Panel
Number of Rows: 2 Row
Voltage Rating: 300 V
Wire Gauge Max: 14 AWG
Wire Gauge Min: 22 AWG
Contact Plating: Tin
Contact Material: Brass
Housing Material: Thermoplastic (TP)
Termination Style: Screw
Flammability Rating: UL 94 V-0
Number of Positions: 6 Position
Maximum Operating Temperature: + 130 C
Minimum Operating Temperature: - 40 C
