Color: Black
Pitch: 0.562 in
Width: 0.87 in
Height: 1.05 in
Length: 6.644 in
Current Rating: 50 A
Mounting Angle: Straight
Mounting Style: Screw
Number of Rows: 1 Row
Voltage Rating: 150 V
Wire Gauge Max: 8 AWG
Wire Gauge Min: 16 AWG
Housing Material: Thermoplastic (TP)
Termination Style: Screw
Flammability Rating: UL 94 V-0
Number of Positions: 10 Position
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
