Width: 67.4 mm
Height: 78.5 mm
Length: 135.9 mm
Coil Type: DC Type
IP Rating: IP67, IP69K
Coil Current: 160 mA
Coil Voltage: 48 VDC
Contact Form: 1 Form X (SPST-NO)
Mounting Style: Upright Flange
Number of Poles: 1 Pole
Coil Termination: Coil Screw
Number of Phases: 1 Phase
Switching Voltage: 800 VDC
Relay Contact Form: 1 Form X (SPST-NO-DM)
Contact Current Rating: 600 A
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 55 C
