GENERAL DATA:
Max fl ow rate (cc/min): 2000
Min outlet pressure (bar): Inlet Pressure – 0.5 (8psi) at maximum flow
Max outlet pressure (bar): 6.5 (94psi)
Total hydrocarbon content (ppm) : < 0.05
Dimensions (LxWxH cm) : 51x44.5x10
Net weight (kg): 12
AIR INLET REQUIREMENTS:
Max Inlet hydrocarbon content : 50ppm
Supply pressure (bar) : 3 to 10 (43psi to 145psi)
Dew-point (°C) : < -20
Temperature (°C) : 1 to 35 (34° to 95°F)
OPERATING CONDITIONS:
Temperature (°C) : 5° to 35 (41° to 95°F)
Humidity (°C) (Max, non condensing) : 80% at 25 (77°F)
IP rating: 20
