Station number: 4 station
Count display:
a. Estimated counting: 0~999999 times
b. Total counting: 0~999999 times
Maximum dynamic range: 24±0.5mm, 60.5±0.5mm
Weight of pressure thing:
a. Gripper: 200±1g
b. Cloth samples hammer: 395±2g
c. Furniture accessories sample hammer: 594±2g
d. Stainless steel butterfly piece: 260±1g
Effective friction diameter of grinding block:
A type: 200g (1.96N) friction head ¢ 28.8-0.084mm
B type: 155g (1.52N) friction head ¢ 90-0.10mm
The relative velocity of Gripper and the grinding station: 50-2r/min
Weight of pressure hammer: 2385±10g
Dimensions: 885mm×600mm×410mm(L×W×H)
Weight: 80kg
Power: Ac 220V, 50Hz
