Color: Black
Pitch: 9.53 mm
Unit Weight: 14.254 g
Current Rating: 20 A
Mounting Style: Panel Mount
Number of Rows: 2 Row
Voltage Rating: 300 V
Wire Gauge Max: 14 AWG
Wire Gauge Min: 24 AWG
Contact Material: Brass
Housing Material: Polybutylene Terephthalate (PBT)
Termination Style: Screw
Flammability Rating: UL 94 V-0
Number of Positions: 2 Position
Maximum Operating Temperature: + 110 C
Minimum Operating Temperature: - 40 C
