Molex 38937-0010 마운팅 엔드 없는 배리어 터미널 스트립 9.53MM BARR STRP W/O MOUNT ST SCREW 10C

Color: Black

Pitch: 9.53 mm

Width: 16 mm

Height: 18.5 mm

Length: 96.9 mm

Current Rating: 25 A

Mounting Angle: Vertical

Mounting Style: Through Hole

Number of Rows: 1 Row

Voltage Rating: 300 V

Wire Gauge Max: 12 AWG

Wire Gauge Min: 22 AWG

Contact Plating: Tin

Contact Material: Brass

Housing Material: Polybutylene Terephthalate (PBT)

Termination Style: PC Pin

Flammability Rating: UL 94 V-0

Number of Positions: 10 Position

Maximum Operating Temperature: + 115 C

Minimum Operating Temperature: - 40 C
