Color: Black
Width: 3.5 mm
Height: 2.5 mm
Length: 4.7 mm
Travel: 0.2 mm
Actuator: Round
Illuminated: Non-Illuminated
Unit Weight: 61.700 mg
Contact Form: SPST
Current Rating: 50 mA
Mounting Style: SMD/SMT
Contact Plating: Silver
Ground Terminal: No
Operating Force: 160 gf
Switch Function: OFF - (ON)
Termination Style: Solder Pad
Voltage Rating DC: 12 VDC
Mounting Direction: Straight
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 25 C
