Depth: 11.5 mm
Shape: Oval
Width: 28.3 mm
Height: 6.55 mm
Length: 40 mm
Frequency: 380 Hz
Impedance: 8 Ohms
Dimensions: 40 mm L x 40 mm W x 6.55 mm H
Width - in: 1.114 in
Width - mm: 28.3 mm
Length - in: 1.575 in
Length - mm: 40 mm
Unit Weight: 25.012 g
Power Rating: 2 W
Cone Material: Paper
Mounting Style: Board Mount
Magnet Material: Neodymium Iron Boron (NdFeB)
Termination Style: Solder Eyelet
Sound Pressure Level: 84 dBA
Self Resonant Frequency: 700 Hz
Maximum Operating Temperature: + 60 C
Minimum Operating Temperature: - 20 C
