Qorvo RFFM6406SR 송수신기 408-455MHz FEM 400MHz ISM 밴드

Gain: 15 dB, 25 dB

Technology: Si

Unit Weight: 1.738 g

Mounting Style: SMD/SMT

Development Kit: RFFM6406PCK-410

NF - Noise Figure: 1.9 dB

Moisture Sensitive: Yes

Operating Frequency: 408 MHz to 455 MHz

Operating Supply Current: 770 mA

Operating Supply Voltage: 2.5 V to 4.2 V

P1dB - Compression Point: - 12 dBm, 30 dBm

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
