System Size (in^3): 4,216
System Size (L): 69
PER/Panel Size (in^3): 2,108
PER/Panel Size (L): 34.5
# of PMTs/panel: 1
Detection Sensitivity *Unshielded (Shielded Source): 2.3 μCi (82mCi)
*Cs-137 point source at 1 meter from the face of the detector. The radiation exposure level is comparable to a 75mm x 150mm Cs-137 lead sealed source buried in 40.0 lbs/ft^3 (0.6 g/cm^3) of scrap.
Detection Method: Polyvinyl Toluene (PVT)
Detector Enclosure Rating: NEMA 4
Energy Range: 20KeV to 3.0 MeV
External Operating Temperature: -4°F to 131°F (-20°C to 50 °C)
Data Output Fields: Date, time, occupancy duration, unit ID, alarm condition, background count, gamma count
Data Output: XML, ASCII
Languages Supported: English, Czech, German, Spanish, French, Italian, Dutch, Polish, Portuguese, Finnish
Agency Compliance: ANSI N42.35 / IEC 62244, ANSI N42.42 / IEC 62755
Accessories:
Camera
External Alarm
Supervisory Software
Neutron Detection: No
