Width: 20.3 mm (0.799 in)
Height: 10.2 mm (0.402 in)
Length: 31.8 mm (1.252 in)
Industry: Medical
Compliance: ANSI; CB; CAN/CSA; EAC; IEC; REACH; RoHS; UL
Efficiency: 83%
Unit Weight: 14 g
Output Power: 6 W
Input Voltage: 36 V to 75 V
Mounting Style: Through Hole
Isolation Voltage: 8 kV
Number of Outputs: 1 Output
Input Voltage - Max: 75 V
Input Voltage - Min: 36 V
Input Voltage, Nominal: 48 V
Output Current-Channel 1: 667 mA
Output Voltage-Channel 1: 9 V
Maximum Operating Temperature: + 75 C
Minimum Operating Temperature: - 40 C
