Temperature range: 0℃ to 45℃
Temp. control accuracy: Up to 2.0°C (*1, 2, 3)
Chamber volume: Approx. 642L
Temp. display/Temp. setting method: Digital display/UP/DOWN method
Heater: 200 W, ON/OFF can be arbitrary turned.
Compressor: 200 W (R-134a), ON/OFF can be arbitrary turned.
Outlet inside chamber: Outlet: 2-Socket × 1 (Drip-proof-type, 5 A in total)
Connecting hole: Left side (φ36 mm)
Circulating method inside the chamber: Circulating by fan motors
Num. of Shelf/Allowable weight: 2 rows x 3 levels/50kg each (Equal weight)
Interior/Exterior material: Stainless steel (except for some part)
Safe devices: Thermostat, Earth leakage breaker
Dimensions inside chamber: 798(W) x 650(D) x 1428(H)mm
Int. Dimension: 900(W) x 800(D) x 1905(H)mm
Weight: Approx. 120kg
Power supply: AC100V/7A /Max.12A (Need a step-down transformer)(*4)
Standard accessories/Others: Shelf × 6 pcs, Pallet × 2 pcs, Drip tray × 1 pc, and Drainage trap on the bottom
Catalog
(*1)The value under ambient temperature 25℃. Useable ambient temperature is 5℃ to 30℃.
(*2)If the set temperature in the chamber is higher than 5℃ above the room temperature, turn the REF. switch OFF. If the set temperature in the chamber is 5℃ or lower than the room temperature, turn the HEAT switch OFF.
(*3)Temperature change immediately after operating the defrosting function is not taken into account.
(*4)When the outlet inside the chamber is used, the power will increase according to the power supply capacity of the device used
