Size: 40 x 8 x 27 Inches,
Weight: 40 Lbs (approx.).
Organs with Speckles (liver, kidneys, etc.)
Sound velocity / Density / Attenuation at 2.25 MHz / Hardness / T2 / Speckles
1435 ± 10 m/s / 0.99 g/cm³ / 1.0 ± 0.2 dB/cm / 20 Shore 00 / 70 ms / VARIABLE
Organs without Speckles (stomach, intestines, etc.)
Sound velocity / Density / Attenuation at 2.25 MHz / Hardness / T2 / Speckles
1400 ± 10 m/s / 0.99 g/cm³ / 1.0 ± 0.2 dB/cm / 20 Shore 00 / 70 ms / NO
Body Tissue
Sound velocity / Density / Attenuation at 2.25 MHz / Hardness / T2 / Speckles
1410 ± 10 m/s / 1.00 g/cm³ / 1.2 ± 0.2 dB/cm / 30 Shore 00 / 65 ms / NO/LOW
Cortical Bone
Sound velocity / Density / Attenuation at 2.25 MHz / Hardness / T2 / Speckles
3000 ± 30 m/s / 2.31 g/cm³ / 6.4 ± 0.3 dB/cm / N/A / N/A / N/A
Trabecular Bone
Sound velocity / Density / Attenuation at 2.25 MHz / Hardness / T2 / Speckles
2800 ± 50 m/s / 2.03 g/cm³ / 21 ± 2 dB/cm / N/A / N/A / N/A
Brain Matter
Sound velocity / Density / Attenuation at 2.25 MHz / Hardness / T2 / Speckles
1400 ± 10 m/s / 0.99 g/cm³ / 1.0 ± 0.2 dB/cm / 20 Shore 00 / 70 ms / YES
