Width: 16.5 mm
Height: 17 mm
Length: 20.3 mm
Inductance: 14.4 H
Turns Ratio: 1:3000
Unit Weight: 15 g
Current Rating: 45 A
Mounting Style: PCB Mount
Frequency Range: 47 Hz to 400 Hz
Termination Style: PC Pin
Voltage Time - Et: 180000 V/us
Secondary Resistance: 747 Ohms
Secondary Voltage Rating: 80 VDC
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
