Width: 50.8 mm (2 in)
Height: 19.1 mm (0.752 in)
Length: 76.2 mm (3 in)
Industry: Medical, Industrial
Dimensions: 76.2 mm x 38.1 mm x 18.6 mm
Output Type: Negative
Output Power: 30 W
Input Voltage: 22 V to 30 V
Mounting Style: Through Hole
Isolation Voltage: 1.5 kVDC
Number of Outputs: 1 Output
Input Voltage - Max: 30 V
Input Voltage - Min: 22 V
Input Voltage, Nominal: 24 V
Output Current-Channel 1: 15 mA
Output Voltage-Channel 1: 0 V to - 2 kV
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 40 C
