3rd Party Software Supported: X-Rite ColorCert, X-Rite Color iQC, X-Rite InkFormulation, X-Rite NetProfiler and many others
Aperture: 2 mm
Battery: Lithium Ion, 7.4VDC, 2200mAh
BestMatch Feature: Yes
Calibration: Automatic on integrated white reference
Color Differences: CIE ∆E* (1976), ∆ECMC, CIE ∆E* (2000), and CIE ∆E* (1994)
Color Spaces: CIE L*a*b*, CIE L*C*h°
Communication Interface: USB 2.0
Connectivity: USB 2.0;
Density Range: 0.0 D – 3.0 D
Density Standards: Status A, E, I, T and G
Dimensions (length, width, height): 18 cm x 7.8 cm x 7.6 cm (7.1" x 3.1" x 3.0")
Embedded NetProfiler Support: Yes
Experience Level: Pressrooms, Press Operators and Production Supervisors looking to reduce make ready waste through tight color control.
G7 Certification: Yes with embedded G7, PSO, Japan Color job templates
Humidity: 30 to 85% RH (non-condensing)
Illuminants: A, C, D50, D55, D65, D75, F2, F7, F11, F12
Import/Export Format: CxF3
Industry Standards: ISO 5-4:2009(E), ISO 13655:2009
Instrument Display: Color touch-screen, 320 x 240 pixels
Inter-Instrument Agreement:
Average: 0.25 ΔEab,
Max: 0.45 ΔEab (for M3: 0.55 ΔEab) (Measurements using X-Rite manufacturing standards at a temperature of 23°C +/- 1°C, 40-60% RH for all measurement modes on 12 BCRA color tiles and a white ceramic reference (D50, 2°))
Internal Temperature & Humidity Sensor: 30 to 85% RH (non-condensing)
Languages Supported: Chinese Simplified, Chinese Traditional, Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Slovenian, Spanish, Swedish, Turkish, Vietnamese
Light Source: Gas filled tungsten (illuminant type A) and UV LED
Macintosh: eXact Manager, DataCatcher and Driver: macOS 10.13, 10.14, 10.15, 10.16 (also on Apple M1 systems), eXact DataMeasure: MacOS X 10.13, 10.14 (32-bit only)
Measurement Conditions: M0, M1 (part 1), M1 (part 2) , M2, M3; also available in Xp variant for flexible packaging substrates
Measurement Geometry: 45°/0° ring illumination optics, ISO 5-4:2009(E)
Measurement Time: < 1 sec
NetProfiler Support: Yes
Observers: 2° and 10°
Operating Temperature Range:
10°C to 35°C
50°F to 95°F
PantoneLIVE Support: Yes; Embedded Pantone Libraries
Pass / Fail: Yes
Scanning Capability: Yes (Optional Upgrade)
Service Indicator: Certification Reminder
Short Term Repeatability - Density: +/- 0.01 D for CMYK (Status E or Status T measurements, maximum error compared to mean value of 10 measurements every 5 seconds at 2.0 D except for M3 Yellow at 1.7 D)
Short Term Repeatability - White: 0.05 ΔEab (standard deviation) White BCRA (Error compared to mean value of 10 measurements every 5 seconds)
Software Development Kit: Yes
Software Modes: Basic
Spectral Analyzer: DRS spectral engine
Spectral Interval: 10 nm
Spectral Range: 400 nm to 700 nm
Spectral Reporting: 400 nm to 700 nm with 10 nm interval
Standards: More than 20'000 standards (incl. data for all M modes); New Color Library Tool to Create and Store Standards
Storage Temperature Range: -20° to 50°C
-4° to 122°F
Supported Devices: Works with ColorCert, InkFormulation, NetProfiler
User Experience: Start-up wizard, configurable, customize toolset, upgradable
Voltage: 12 VDC @ 2.5 A
Weight:
700 g
1.6 lbs.
What's Included?: USB cable, power supply, CD with software and documentation, docking/charging station, quick start guide, carrying case, device certificate
Windows Windows XP (32bit), Windows 7 (32 and 64 bit), Windows 8 (32 and 64 bit), Windows 10 (32 and 64 bit)
