EAST TESTER ET4502 벤치탑 LCR 미터 (10-10KHz)

- Testing frequency: 10-10KHz continuous adjustable, 1Hz step[1]by-step

- Display screen: Display screen 3.5 inch TFT LCD

- Number of display digits: Principal parameter: 5 digit，Secondary parameter: 5 digit

- Measured parameter: Principal parameter: L/C/R/Z，Secondary parameter: X/D/Q/θ/ESR

- Measurement Range:

L：0.001μH～9999H

C：0.001pF～99.999mF

R：0.0001Ω～99.99MΩ

- Basic accuracy: 0.1%

- Measuring display speed: 2 time/s (slow), 4 times/s (medium), 8 time/s (fast)

- Internal bias: 0-1500mV adjustable, at a step of 1mV.

- Testing level: 0.01~2V adjustable, at a step of 1mV.

- Signal source output impedance: 30Ω、100Ω

- Calibration function: Open circuit calibration, short circuit calibration

- Screening function: The limit range of screening can be set to -50%～＋50%, and the fixed points are 1%, 5%, 10% and 20%.

- Comparator: 5 groups sorting,3 groups of qualified setting, one group of unqualified setting, one group of auxiliary setting

- Interfaces: standard: RS232（or 485）, USB Device, Handler ;

- Others: Support dc resistance (DCR), electrolytic capacitor measurement model,Adjustment of backlight brightness, Chinese and English are optional

General technical specifications

- Power supply voltage: 220V.AC±10%, or 110V.AC±10%, 45~65Hz;

-  Power consumption: <10W;

- Display: 3.5 inch TFT LCD screen, resolution 480 *320, color 16M;

- Temperature range: Operating state 10℃~+40℃, non-operating state -10℃ ~+60℃;

- Humidity range: 0 ~ 40 C, < 90% relative humidity;

- Interface: RS232 (or 485), USB Device, Handle,

Standard accessories

- Three core power cord(30A51)

- 4-terminals of kelvin testing cable(35A51)
