MATRIX MPS-3063XP 다중 채널 DC 전원 공급 장치 (31V, 6A)

Rated output:

Voltage: 0 ~ 31V * 3

Electric current: 0 ~ 6A * 3

Load regulation:

Voltage: ≤0.01%+  3mV

Electric current: ≤0.01%+  3mA

Power regulation:

Voltage: ≤0.01%+  3mV

Electric current: ≤0.01%+  3mA

Set resolution:

Voltage: 1mV

Electric current: 1mA

Readback resolution:

Voltage: 1mV

Electric current: 1mA

Set accuracy:

Voltage: ≤0.03%+  10mV

Electric current: ≤0.1% + 8mA

Readback accuracy:

Voltage: ≤0.03%+  10mV

Electric current: ≤0.1% + 8mA

Ripple and noise:

Voltage rms: ≤2mVrms

Electric current: ≤5mArms

Series and parallel setpoint accuracy:

Voltage: ≤0.02%+  10mV

Electric current: ≤0.1%+  30mA

Memory:

Store / Call: 40 groups

Features: Timing off output

Timer: time setting: 0.1s ~ 99999.9s

Resolution: 0.1s

Operating temperature: 0 ~ 40 ° C

Bare metal size (mm): 255 * 110 * 380

Packing size (mm): 325 * 210 * 475

Net weight (kg): 11

Gross weight (kg): 13
