Buồng thử phun nước IPX1–IPX4 LIB R-800C (810L)

Kích thước trong (mm): 900 × 950 × 950

Kích thước tổng thể (mm): 1180 × 1420 × 1920

Dung tích hữu dụng (L): 810

Bán kính ống dao động: 400 mm

Kích thước khay nhỏ giọt: 600 × 600

Đường kính lỗ phun: φ0.4 mm

Khoảng cách lỗ: 50 mm

Góc quay ống dao động: 0 ~ ±180° (có thể điều chỉnh)

Tốc độ quay bàn xoay: 1 vòng/phút (có thể điều chỉnh)

Điều khiển áp lực nước: Lưu lượng kế

Bộ điều khiển: Màn hình cảm ứng LCD màu lập trình, kết nối Ethernet

Hệ thống cấp nước: Bồn nước, bơm tăng áp, cấp nước tự động, hệ thống lọc nước

Thiết bị an toàn: Bảo vệ quá nhiệt; Bảo vệ quá dòng; Bảo vệ thiếu nước; Bảo vệ rò điện; Bảo vệ thứ tự pha

Vật liệu bên ngoài: Thép tấm phủ lớp bảo vệ

Vật liệu bên trong: Thép không gỉ SUS304

Cửa sổ quan sát: Kính cách nhiệt 2 lớp, có cần gạt nước

Advantages

1. Integrated Multi-Level Testing to Save Lab Space: LIB's IPX1 IPX2 IPX3 IPX4 Water Spray Test Chamber incorporates both a drip box (IPX1/IPX2) and an oscillating tube (IPX3/IPX4) within a single enclosure. This all-in-one configuration allows for six levels of water ingress testing in one chamber, optimizing lab footprint and improving workflow efficiency.

2. Automatic Water Filtration and Recycling System: A closed-loop water recycling system with automatic refill ensures continuous operation while minimizing water and energy consumption. This system supports unattended testing, reducing labor requirements and operational costs.

3. Compliance with International Standards: The chamber is fully compliant with IEC 60529 and other relatedstandards: ①IPX1: 1 mm/min drip rate for at least 10 minutes on a rotating turntable at 1 rpm. ②IPX2: Same drip rate at

15° tilt, tested in four directions for 2.5 minutes each (total 10 minutes). ③IPX3: Oscillating tube sprays water with ±60° swing, 0.4 mm nozzle diameter, 50 mm spacing, and 0.07 L/min per nozzle for at least 10 minutes. ④IPX4: Swing angle extends to ±180°, simulating more severe splash conditions.

4. Flexible Sample Handling for Diverse Products: Height-adjustable internal turntable with a 15° inclined plate for IPX2 testing. Supports up to 50 kg and can be customized in size to accommodate various sample dimensions.

5. Durable SUS304 Stainless Steel Construction: Entire chamber is fabricated from SUS304 stainless steel, offering excellent corrosion resistance under high temperature (~800°C), high humidity, and continuous spray conditions, while ensuring environmental compliance.

6. Multi-Angle Spray Systems: ①IPX1/IPX2: Stainless steel drip box with uniform apertures, simulating vertical drip at 1 mm/min.②IPX3/IPX4: Stainless steel oscillating tube with φ0.4 mm evenly spaced nozzles, ±60° swing, simulating oblique rain conditions.

7. Transparent Viewing Window with Built-In Illumination: Equipped with a clear observation window, manual wiper, and LED lighting for real-time inspection, facilitating accurate experiment logging and rapid fault diagnosis.

8. Waterproof Sample Power Supply: Adjustable-height turntable with tilt support and integrated power supply, allowing live power-on testing of electronic devices during waterproof testing to replicate real-world conditions.
