Optical system: Parallel-optics type (zooming type), apochromatic optical system
Observation method: brightfield
Can be upgraded for other observation methods: darkfield, fluorescence, Simple Polarizing
Aperture diaphragm: Zooming body built-in
Zoom: Motorized
Magnification: 6.3 - 157.5x (With objective 1x, Eyepiece 10x)
Total magnification: 3.15- 945x (Depending on objective and eyepieces used)
Can be upgraded to use up to 2 objectives (magnification: 0.5x; 1x; 1.6x; 2x) at the same time
Auto Link Zoom (ALZ) supports seamless viewing at different scales: ALZ automatically adjusts the zoom factor to maintain the same field of view when switching objective lenses. This function enables seamless switching between whole organism imaging at low magnifications and detailed imaging at high magnifications. (in case using 2 objective lens)
Tube: P2-TERG 50 Trinocular Tilting Tube, Eyepiece inclination: 0°-30°, Eyepiece: port 100:0/50:50
Eyepieces: C-W10xB (F.N. 22), with diopter adjustment
Objective: P2-SHR Plan Apo 1x (NA: 0.156, WD: 60mm)
Focus Unit: P2-MFU Motorized Focus Unit (Stroke: Up 96mm/Down 4mm)
Nosepiece: P2-RNI2 Intelligent Nosepiece
Remote control: provides easy access to zoom and focus controls and is designed for both right- and left-hand use. The remote control contains an LCD monitor with an adjustable backlight that provides at-a-glance information about zoom factor, objective lens, filter cube and LED DIA brightness.
Base: P2-DBL LED Diascopic Illumination Base:
Can control the LED brightness
Built-in OCC illuminator: generating minimal heat, consumes little power and has a long life
Enhances the contrast of uneven surfaces, such as that of an embryo
C-FDF Flexible Double Arm Fiber Illumination Set:
LED Light Source for Fiber Illuminator, lifetime: approximately 30,000 hours at maximum light intensity
The direction and angle of illumination can be changed to suit the sample by making adjustments with these double arms.
The fiber holder position can also be changed to obtain the optimal position for illuminating samples
Components:
SZM25 main body: 01 unit
Tube: 01 unit
Eyepiece 10x: 02 units
Nosepiece: 01 unit
P2-SHR Plan Apo 1X: 01 unit
Diascopic Illumination Base: 01 unit
Motorized Focus Unit: 01 unit
Remote controller: 01 unit
Arm Fiber Illumination: 01 set
Dust cover: 01 unit
