Máy đo độ dày bằng siêu âm NOVOTEST UT-1M

TÍnh năng

Dải đo độ dày (0,8 - 1000mm)

Kiểm soát lợi ích khách hàng

Khả năng điều chỉnh V của đầu dò

Vỏ chống sốc

Cho phép lưu cài đặt dò

Tăng âm lên tới 20 dB

Thông số kỹ thuật

Dải đo độ dày, mm: 0,8 ... 300

Đầu dò 10 MHz - P112-10-6 / 2: (dải 0,8-30mm)

Đầu dò 5 MHz - P112-5-10 / 2: (dải 1-75mm)

Đầu dò 2,5 MHz - P112-2,5-12 / 2: (dải 2-300mm)

Dải thiết lập của tốc độ siêu âm, m / s: 1000-9999

Số đọc rời rạc trên chỉ báo kỹ thuật số, mm: 0,1

Thời gian đáp ứng: ≤2s

Độ chính xác đo cơ bản, mm: ± (0,001 T +/- 0,1)

Kích thước tổng thể, mm: 120x60x25

Dải nhiệt độ hoạt động, ° C: -5 đến +40

Nguồn điện: 2 pin AA

Thời gian làm việc liên tục: ≥10 tiếng

Trọng lượng của đơn vị điện tử với pin: 0,2kg

Cung cấp bao gồm

Máy đo độ dày siêu âm

Đầu dò (đầu đo) - 1 (phụ thuộc vào dải độ dày kiểm soát mong muốn)

pin 2 AA

Bộ sạc

Cáp

Giấy chứng nhận hiệu chuẩn của nhà sản xuất

Hướng dẫn vận hành

Hộp đựng

Phụ kiện mua thêm:

Khớp nối; Đầu đo UT; Khối hiệu chuẩn

- Đầu đo qua lớp sơnEcho-Echo cho các máy NOVOTEST UT-1M (-IP, -ST, -2A)

- Đầu đo nhiệt độ cao (lên tới 250°C) cho các máy  NOVOTEST UT-1M (-IP, -ST, -2A)

Chi tiết

Description:

- Ultrasonic Thickness Gauge NOVOTEST UT-1M is used for operational non-destructive testing of the thickness of products with one-way access, at the moment this method is the most common in the world for solving such tasks.

- The method is based on the property of materials to conduct ultrasound, ultrasonic wawes are excited with the piezoceramic plate in the transducer and penetrates into the material through the couplant, then reflected from the bottom surface of the tested sample, and returns to the transducer. Based on the obtained sound transit time in the material, the device calculates the thickness in accordance with the velocity of propagation of ultrasonic waves in the test sample. The thickness value is displayed on the device’s display, the measurement process takes about 1 second.

Advantages:

Wide range of measuring thicknesses

- Convenience and ease in operation

- Minimum number of controls

- Select the type of probe through single button

- Preset velocity of ultrasound

- Graphical display with backlight

- Compensation of probe delay

- Control of the batteries

- Mapping the presence of acoustic coupling on the graphic display

- Fixation of the last measurement result in the removal of the transducer surface

Datasheet
