Thông số kỹ thuật:
Điện áp AC:
Dải đo tối đa: 40 ... 400 V
Độ phân giải: 0.01 V
Độ chính xác: ±1% của Rd.
Dòng điện xoay chiều AC
Dải đo tối đa: 0 ... 80 A
Độ phân giải: 0.01 A
Độ chính xác: ±1% của Rd.
Công suất hoạt động
Dải đo tối đa: 0 W ... 32 kW
Độ phân giải: 0.01 W
Độ chính xác: ±1% của Rd
Công suất phản kháng
Dải đo tối đa: 0 VAR ... 32 kVAR
Độ phân giải: 0.01 VAR
Độ chính xác: ±1% của Rd
Công suất biểu kiến
Dải đo tối đa: 0 VA ... 32 kVA
Độ phân giải: 0.01 VA
Độ chính xác: ±1% của Rd
Hệ số công suất
Dải đo tối đa: 0 ... 1
Độ phân giải: 0.01
Độ chính xác: ±1% của Rd.
Thông số kỹ thuật chung
Tốc độ đo: 26000 Hz
Bộ nhớ lưu trữ: Bộ nhớ trong
Dung lượng lưu trữ: 32 GB
Dung lượng bộ nhớ (thông tin bổ sung): pha riêng biệt: 22000 bản ghi dữ liệu, pha tóm tắt: 38000 bản ghi dữ liệu
Khoảng thời gian lưu trữ từ: 1 s
Khoảng thời gian lưu trữ đến: 60 phút
Dòng tiêu thụ kìm đo dòng: 100 mA DC
Đường kính cáp tối đa: 10 mm
Tiêu chuẩn an toàn: CAT III 300V
Cầu chì: 250mA, FA, IR>=30kA
Ngôn ngữ menu: Tiếng Đức, Tiếng Anh (GB), Tiếng Anh, Tiếng Tây Ban Nha, Tiếng Pháp
Lớp bảo vệ (thiết bị): IP40
Nguồn điện: 100 ... 240 V 50/60 Hz (+/- 10%) (giữa dây trung tính và pha A)
Khối lượng: 202 g
Điều kiện hoạt động: -5 ... 40 °C, 0 ... 80% RH
Điều kiện bảo quản: -5 ... 40 °C, 0 ... 80% RH
Kích thước (D x R x C): 123 x 96 x 36 mm
Description
Clamp Meter for energy monitoring / configuration and data transfer via app / measurement without interrupting the power supply / incl. test leads / compact design
The Clamp Meter measures current and voltage values using the connected current transformers and test leads. From this, the active, apparent and reactive power are determined and transmitted to the measuring platform every second via Wi-Fi. The data is then filed historically on the Clamp Meter, processed graphically and can be analysed or exported. The measurement with the Clamp Meter is carried out using Rogowski coils or folding current transformers.
Alternatively (if no internet connection is available), the data can be recorded in the built-in 32 GB flash memory in the form of a CSV file for further processing at a later date. An SD card adaptor is also available as an accessory, which means that the recording duration is more than one year, even when recording to the second. It is also possible to send the CSV files periodically by e-mail, upload them to a server via FTP or transfer them to the measurement platform once the measurement has been completed. Interaction with the Clamp Meter is mainly via Wi-Fi and web browser or via app (BLE).
Power is supplied and measured via magnetic measuring tips and connection terminals or probes. The Clamp Meter can be connected into any main and sub-distribution board as well as into devices and systems - the power supply does not have to be interrupted. Managing the power supply is the top priority. Without measuring consumption and recording instrumental values such as current, voltage, frequency and power, it is virtually impossible to improve efficiency. The Clamp Meter makes it possible to monitor the entire energy consumption and helps to reduce energy costs.
Highlights
- active, apparent and reactive power
- power factor and electrical energy
- 32 GB internal memory
- app for Android
- data as CSV file
- measurement via Rogowski coils
- no additional mains connection necessary
