Modular 1X2 RJ45 Pulse Electronics JXD0-2005NL

Color: Black

Pitch: 2.54 mm

Gender: Jack (Female)

Shielding: Shielded, EMI Fingers

USOC Codes: RJ45

Application: 10/100 Base-TX

Unit Weight: 16.524 g

Configuration: 1x2

Tab Direction: Tab Down

Mounting Angle: Right Angle

Mounting Style: Through Hole

Contact Plating: Gold

LED L / R Color: Green / Yellow

Number of Ports: 2 Port

Contact Material: Copper Alloy

Termination Style: Solder

Number of Contacts: 8 Contact

Flammability Rating: UL 94 V-0

Number of Positions: 8 Position

Performance Category: Cat 5

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

Number of Positions / Contacts per Port: 8P8C
