Tụ phim liên kết DC 7uF 900 volt 5% 4 chân 37.5x10.2mm LS Vishay Roederstein MKP1848570094P4

ESR: 16 mOhms

Life: 100000 Hour

Width: 18.5 mm (0.728 in)

Height: 43 mm (1.693 in)

Length: 35.5 mm (1.398 in)

Tolerance: 5 %

Dielectric: Polypropylene (PP)

Capacitance: 7 uF

Unit Weight: 21 g

Lead Spacing: 37.5 mm (1.476 in)

Lead Diameter: 1 mm

Pitch Spacing: 10.2 mm

Number of Pins: 4 Pin

Capacitance - nF: 7000 nF

Termination Style: Radial

Voltage Rating DC: 900 VDC

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 40 C
