Measurement Range:
PE contact on steel - 1.00 - 9144mm (0.040 - 360”)
IE on steel - 1.27 - 25.4mm (0.050 - 1”)
IE on plastic - from 0.127mm (0.005”)
EE contact on steel - 2.54 - 914.4mm (0.100 - 36”)
IEE on steel - 0.152 - 12.7mm (0.006 - 0.5”)
EEV contact on steel - 2.54 - 152.4mm (0.100 - 6”)
Resolution: 0.01mm (0.001”); 0.001mm (0.0001”) selectable
Operating Temperature: -10 to 60ºC (14 to 140ºF)
Power Supply: 3 x AA batteries and via USB
Battery Life: Alkaline: greyscale 35 hrs; colour 12 hrs
Nicad: greyscale 10 hrs; colour 5 hrs
NI-MH: greyscale 35 hrs; colour 12 hrs
Gauge Weight: 383g (13.5oz) - including batteries
Gauge Dimensions: 63.5 x 165 x 31.5mm (2.5 x 6.5 x 1.24”)
Packing List: Unit; standard 1/4" Delay Line Transducer (2 Delay Tips – 3/8” & 1/2” L) & Cable; Couplant; Manual; Certificate of Calibration; AA Batteries and Plastic Carrying Case.
