Temperature range: RT+10℃～60℃ (Adjustable, ozone will decompose when temp. above 60 ℃)
Temperature fluctuation: ±0.5℃
Accuracy of Tem Distribution: ±2.0℃
Max Tep of Ozone: 60℃ (When the temperature is above 60 ℃, ozone decomposition rate will get rapid self-decomposition.
Heating time: around 20min from RT to 60 ℃
Humidity range: ±3.0%.
Humidity fluctuation: ±2.0%.
Ozone concentration accuracy: 50~1000pphm (adjustable, low viscosity)
Air flow amount: 20～70L/min
Air flow rate: 12～16mm/s
Revolving speed of sample holder
Ozone Accuracy: ±5.0% F.S
Ozone fluctuation: ±2.5pphm
Specimen fixture: one set of three groups of experimental static fixture
Volume: 150L
Inner size: W500 X H600 x D500mm
External size: W1050 X H1700 x D1100mm
Weight: 300kg
Power supply: AC380±5%V /50±0.5Hz
Power: 4.0KW
