Meanwell MDR-100-24 DIN Rail Power Supply (96W, 24V, 4A)

OUTPUT:

DC VOLTAGE: 24V

RATED CURRENT: 4A

CURRENT RANGE: 0 ~ 4A

RATED POWER: 96W

RIPPLE & NOISE (max.): 150mVp-p

VOLTAGE ADJ. RANGE: 24 ~ 30V

VOLTAGE TOLERANCE: ±1.0%

LINE REGULATION: ±1.0%

LOAD REGULATION: ±1.0%

SETUP, RISE TIME: 3000ms, 50ms/230VAC 3000ms, 50ms/115VAC at full load

HOLD UP TIME: 50ms/230VAC 20ms/115VAC at full load

INPUT

VOLTAGE RANGE: 85 ~ 264VAC, 120 ~ 370VDC

FREQUENCY RANGE: 47 ~ 63Hz

POWER FACTOR:

PF≧0.95/230VAC

PF≧0.98/115VAC at full load

EFFICIENCY: 86%

AC CURRENT: 1.3A/115VAC, 0.8A/230VAC

INRUSH CURRENT: COLD START 30A/115VAC 60A/230VAC

LEAKAGE CURRENT: <1mA / 240VAC

ENVIRONMENT:

WORKING TEMP.: -10 ~ +60℃ (Refer to "Derating Curve")

WORKING HUMIDITY: 20 ~ 90% RH non-condensing
