Color: Gray
Pitch: 5.2 mm
Width: 78 mm
Height: 39 mm
Length: 15.8 mm
Unit Weight: 43.800 g
Current Rating: 24 A
Mounting Style: Snap-On
Voltage Rating: 500 V
Wire Gauge Max: 12 AWG
Wire Gauge Min: 28 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 28 AWG to 12 AWG
Connection Method: Spring Cage
Flammability Rating: UL 94 V-0
Number of Positions: 15 Position
