Vishay General Semiconductor BPW24R PIN光电二极管 TO-18 400-1100nm +/-12度

Width: 5.5 mm

Height: 6.15 mm

Length: 5.5 mm

Fall Time: 7 ns

Rise Time: 7 ns

Unit Weight: 1.169 g

Dark Current: 2 nA

Photocurrent: 55 uA

Responsivity: 0.55 A/W

Mounting Style: Through Hole

Peak Wavelength: 900 nm

Vr - Reverse Voltage: 60 V

Pd - Power Dissipation: 210 mW

Half Intensity Angle Degrees: 12 deg

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 55 C
