ARI HypotULTRA® 7804 电气安全测试仪 (5 kV-30 mA AC, 6 kV-20 mA DC Hipot, 40 Amp Ground Bond Tester, CE listed)

AC Hipot

Voltage Output = 0-5000VAC

Leakage Current Limits = 0.000mA-30.0mA

Output Frequency = 50/60Hz

DC Hipot

Voltage Output = 0-6000VDC

Leakage Current Limits =0.0000-20,000µA

DC Ripple ≤ 4% Ripple RMS at 6 KVDC @ 20mA, Resistive Load

Ground Bond

AC Output Current = 1.00A-40.00A

AC Output Voltage = 3.00-8.00 V

Resistance Range = 0-600mΩ

Continuity

DC Output Current = 0.001A-1ADC

Resistance Range = 0.000-10,000Ω

Insulation Resistance

Voltage Output = 10-6000VDC

Resistance Range = 0.1MΩ-50.0GΩ

Dimensions (W x H x D): 16.92" x 3.50" x 15.75" (430 x 88.1 x 400 mm)

Weight: 41 lbs (18.6 kg)
