Atomtex AT5350/1 标准辐射测量机 (x & γ)

Measurement range:

Direct current rate: 1•10^-15 – 1•10^-6 A

Electric charge: 1•10^-15 – 1•10^-6 C

Charge by the method of numerical integration of current: 1•10^-14 – 1•10^-1 C

Measurement accuracy: ≤(0.1 – 0.5)%

Measurement range:

- Air kerma rate: 0.4 µGy/min – 10 kGy/min

- Air kerma: 0.05 µGy – 15 Gy

- Air kerma by the method of numerical integration of kerma rate: 0.05 µGy – 1.5 MGy

X-ray and gamma radiation energy range: 8 keV – 1.33 MeV

Leakage current: 1•10^-15 A max

Integration time: 99,999 s max

Power supply: 230 VAC, 50 Hz

Power consumption: 12 V•A max

Overall dimensions / weight: 294х112.5х250 mm / 3.8 kg

Delivery set:

Electrometer measurement unit (Electrometer)

Optional ionization chambers by PTW-Freiburg (Germany):

TM23342 Parallel-plane X-ray chamber (0.02 cm3)

TМ31010 Cylindrical ionization chamber (0.125 cm3)

TМ30010 Thimble ionization chamber (0.6 cm3)

TМ23361 Cylindrical ionization chamber (30 cm3)

TМ32002 Spherical ionization chamber (1000 cm3)
