Dwyer 2-5000-500PA-NPT 紧凑型低差压计 – 无需电源，可靠且低成本 (Differential, 500 Pa, NPT Male, 1/8 in)
制造商: Dwyer Model: 2-5000-500PA-NPT - 联系
Dual: false
Weight: 170.1 g
Accuracy: ± 5 %
Dial Dia: 2 1/16 in
Materials: Glass Filled Polyamide, Polycarbonate
Compliance: RoHS 2
Accuracy Note: ± 5% of FS at 70°F (21.1°C).
Pressure Type: Differential
Pressure, Max: 500 Pa
Pressure, Min: 0 inH₂O
Compliance Note: Meets the technical requirements of EU Directive 2011/65/EU (RoHS II).
Pressure Limits: Up to 30 psi
Materials, Wetted: Consult Factory
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Corrosive Dry Gases
Mounting Orientation: Vertical Diaphragm
Process Connection Note: Barbed, for 3/16˝ ID tubing (standard); 1/8˝ male NPT (optional).
Process Connection Size: 1/8 in
Process Connection Type: NPT Male
Operating Temperature, Max: 120 °F
Operating Temperature, Min: 20 °F
