Honeywell PX6ie 高性工业条码打印机 (Thermal Transfer, Direct Thermal)

Print Method: Thermal Transfer and Direct Thermal

Dimensions (L x H x W): 482 mm x 238 mm x 335 mm (19.0 in x 9.4 in x 13.2 in)

Print specifications:

    Max. Print Width: 167.4 mm (6.59 in)

    Max. Length:

          At 203 dpi: 4095 mm (161 in)

          At 300 dpi: 2775 mm (109 in)

          At 406 dpi: 1016 mm (40 in)

Print speed: For 203/300 dpi: 100–225 mm/s (4–9 ips)

Resolution:  8 dots/mm (203 dpi), 11.8 dots/ mm (300 dpi)

Label Roll Maximum Diameter: 213 mm (8.38 in)

Label Roll Core: 38–76 mm (1.5–3 in)

Ribbon roll:

    Roll Max. Diameter: 80 mm (3.15 in), approx. 450 m

Datasheet

User's manual
