INSIZE 5106-M50T Zoom Stereo Microscope (With Universal Stand) (10X; Trinocular)

Optical tube: Trinocular

Eyepiece(wide field): 10X(view field: Ø22mm)

Objective: 0.8X~5X (zoom)

Zoom ratio: 1:6.3

Pupil distance: 55~75mm

Diopter adjustment: ±5 diopter (two eyepieces)

Working distance of objective: 115mm

Max workpiece height: 300mm

Illumination: adjustable reflected LED ring light

Power supply: 110/220V, 50/60Hz

Dimension (LxWxH): 790x230x430mm

Weight: 20kg
