Temperature Range (℃ / ℉) Amb. 0~60 /
Fluctuation at 37℃ (±℃ / ℉)0.2 / 0.36
Variation at 37℃ (±℃ / ℉) 0.15 / 0.27
Dimension (W×D×H) Internal (mm / inch) 600×500×500 /
Overall (mm / inch) 760x760x1690 /
Net Weight (kg / lbs) 350
Electrical Requirements (230V, 50 / 60Hz) 9A
Cat. No. AAH28112K
Detail
Operating Features
- Temperature range: 0℃ to 60℃.
- Independent temperature and timer control of each chamber using microprocessor PID.
- Simple calibration and auto-tuning functions
- Digital timer with Delayed ON/OFF function: ranging from 1 min to 99 hr 59 min.
- Three most commonly used temperature settings programmable.
- Up to 9 temperature steps and maximum 200 cycles of repetition programmable for each profile.
- Adjustable 3 step fan speed with defrosting time and period control.
- Intuitive control panel with bright LED display (0.1℃ resolution) and touch-sensitive keypad.
- RS-232 interface.
Constructional Features
- Four independently controlled 150L chambers (Model IL-11) merged into a single unit for space saving.
- Convenient sample monitoring without affecting chamber temperature via the inner tempered-glass door.
- Detachable shelves and rounded inner chamber corners allowing convenient cleaning.
- Built-in casters for easy transport and installation.
| Model | IL-11-2C | |
|---|---|---|
| Chamber Volume (L / cu ft) | 600 / 21.1 [150 / 5.3 x 2 Chambers] | |
| Refrigerator (Hp) | 1/8 HBP x 2EA | |
| Temperature | Range (℃ / ℉) | 0 to 60℃ / 0 to 140℉ |
| Fluctuation 1) at 25℃ (±℃ / ℉) | 0.1 / 0.18 | |
| Variation 1) at 25℃ (±℃ / ℉) | 0.5 / 0.9 | |
| Dimension (W×D×H) |
Interior (mm / inch) | 600x500x500 / 23.6x19.7x19.7 Per chamber |
| Exterior (mm / inch) | 760x760x1690 / 29.9x29.9x66.5 | |
| Net Weight (Kg / lbs) | 200 / 441 | |
| Electrical Requirements (230V, 60Hz) | 9A | |
| Cat. No. | AAH28111K | |
| Electrical Requirements (230V, 50Hz) | 9A | |
| Cat. No. | AAH28112K | |
| Electrical Requirements (120V, 60Hz) | 16.5A | |
| Cat. No. | AAH28113U | |
1) Technical data according to DIN 12880.
