JPT SC 跳线

Application

Telecommunication System

Testing Facility

CATV System

Long-haul Telecommunication

LAN System

Fiber mode: SM

End-face Finishing: PC/ UPC/ APC

Insertion Loss (dB): ≤0.30/ ≤0.30/ ≤0.30

Return Loss (dB): ≥45/ ≥50/ ≥60

Operating Wavelength(um): 1310, 1550

Fiber mode: MM

End-face Finishing: PC

Insertion Loss (dB): ≤0.30

Return Loss (dB): ≥35

Operating Wavelength(um): 850

Connector Type: SC, LC, FC, MTRJ, E2000

Diameter (mm): Φ 0.9、Φ 1.2、Φ 1.6、Φ 2.0、Φ 3.0

Exchangeability (dB): ≤0.20

Repeatability (dB): ≤0.20

Operating Temperature(℃): -40 ~ +75

Storage Temperature (℃): -40 ~ +85
