Lisun CSS61000-11T 电压周波跌落测试仪 (AC Sine, 0~110% of 380V)

Wave Generator: AC Sine Wave

Range of Voltage Variations: 0~110% of 380V

IEC Level Build-in:  100%, 80%, 70%, 40%, 0%

Dip Phase Set:  0°~360° (1° Step)

Duration Time of Voltage Variation:  0.5~9999.5T

Internal Time of Voltage Variation:  1s~9999s

Voltage Dip Count: 0~9999 times

Operating Mode:  Choose 1 to 3 phases to automatic dip at the same time

Trigger Mode:  Manual, Auto and 50ms

Power Capacity For EUT: 3 Phase AC 380V±10%, 20A max

Working Power:  AC220V (Option 110V)±10%, 50/60Hz

Dimension (DxWxH) : 56x58x130cm

Gross Weight:  About 150kg
