Lisun LSG-3000CCD Moving Detector Goniospectroradiometer (380nm ~ 780nm, ϕ 600mm)

1) The mirror rotates around the tested luminaire with an angle of (γ)±180° and the tested luminaire rotates around itself with an angle of (C)±180°

2) The accuracy of angle: 0.1° Resolution of angle: 0.01°

3) Luminosity Testing Range: Illuminance 0.001lx~99,999lx; Light Intensity 1.0cd~10^7cd(detector)

4) Accuracy of photometry: CIE Class A or Class L (option)

5) Testing Accuracy: 2%(Under Standard lamp); Stray Light: less than 0.1%

6) Work with high accuracy and quick CCD Spectroradiometer to measure spatial color parameters.

7) Accuracy of chromaticity coordinate: ±0.0015 or ±0.0005(under A standard lamp)

8) Spectral Range Wavelength: 380nm ~780nm; Accuracy of wavelength: ±0.5nm

9) English version software can run in Win7, Win8 or Win10

Measure Size (mm): Diameter=600

Measure Weight (Kg): 20

Measure Power(W): 600V/10A,AC/DC

System Configuration:

A. LSG-3000CCD Goniospectroradiometer System

B. SLS-150W DC Standard Light Intensity Lamp

C. LS2012 Digital Power Meter

D. DC3010 CC & CV DC Power Source

E. LSP-500VAS AC Power Source: 500VA AC Power Source

F. CASE-19IN 19inch Standard Instruments Cabinet.

G. High Precision CCD Spectraidomeeter

H. Accessories and Adjustable Tripod for Spectraidomeeter
