Design volume/Effective volume: 287Litre/200Litre
Mixing jar Inner material: 304 stainless steel
Dimension: Ф750×650mm；Can be used for vacuum mixer TOB-XFZH-200 as mixing jar
Discharging valve : G1-1/2 "(DN38);
Barrel with push handle, barrel bottom with four move wheels, easy for transfer.
Cooling/heat preservation : Bottom and side with cooling jacket
Top cover: With two small vision Windows, a shoot light, DN40 feeding tube, vacuum interface, vacuum pressure gauge and other spare interface.
Mixing speed: 35rpm without adjusting, 304 stainless steel Stirring shaft
Mixing power: 1.5kw/4P
Mixing theory: Combined impeller rotation do over type, make the material/week to cycle up and down, to ensure that the material is not deposit.
Vacuum degree: ≤-0.098Mpa, can Keep 24 hours is not lower than 0.085 Mpa
