Yamato BT300 摇动水浴孵化器 (34L)

Method: Reciprocating shaking system, Stirring by pump

Operating temp. range: Room temp. +5°C to 80°C(when top cover is installed)

Temperature control accuracy: ±0.02°C to 0.08°C

Temperature distribution accuracy: ±0.1°C

Temperature rising time: Approx. 120 min.

Shaking frequency: 20 to 160 times/min

Shaking width: 10 to 40mm (adjustable)

Material (Interior): Stainless steel

Temp. Controller: PID control by microprocessor

Temp. Sensor: Pt resistance thermometer+K thermocouple (double sensor)

Temp setting/display method: Digital setting

Overheat protector: ON/OFF control by microprocessor

Overheat protect setting method: Digital setting

Heater: Copper pipe heater (nickel plated) 2.5kW

Stirring System: Magnet pump 10W

Shaker: Gear motor 40W

Shaking speed setting system: Analog setting

Flask: Round, Erlenmeyer flask 100/300/500ml, 24/10/6pcs.

Shaking Rack (Dimensions W×D×Hmm): 2 pcs. 290×290×170

Spring Pitch: 20mm (both length and width)

Internal dimensions(W×D×H mm): 532×350×250mm

External dimensions(W×D×H mm): 809×414×325mm

Remarks(dimensions): Internal capacity  34L(When the water is full)

Power Source: AC220V Single phase with step-down transformer

Weight: 48kg
