Weight: 1.03 lb
Deadband: 20 to 30 psi
Compliance: CE
Switch Note: 2 each SPST snap action, normally closed (NC), 20 A @ 120 VAC, 12 A @ 240 VAC, 9.6 A @ 240 VAC (3 phase), 8.6 A @ 32 VDC, 3.1 A @ 120 VDC, 1.6 A @ 240 VDC. 1.5 HP @ 120 VAC, 2 HP @ 240 VAC, 3 HP @ 240 VAC (3 phase), 0.25 HP @ 32/120/240 VDC.
Switch Type: SPST Snap, NC
Pressure Type: Gauge
Pressure, Max: 100 psi
Pressure, Min: 25 psi
Repeatability: ± 5 psi
Switch Rating: 20 A @ 120 Vac, 12 A @ 240 Vac, 9.6 A @ 240 Vac (3 phase), 8.6 A @ 32 Vdc, 3.1 A @ 120 Vdc, 1.6 A @ 240 Vdc.ac
Pressure Limits: Up to 129 psi
Enclosure Ratings: None
Materials, Wetted: Aluminum, Buna-N (NBR)
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Corrosive Dry Gases
Mounting Orientation: Not Position Sensitive
Set Point Adjustment: Internal Screw
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Operating Temperature, Max: 140 °F
Material Construction Option: Aluminum
