Width: 2.45 in
Height: 2.63 in
Length: 3.7 in
Accuracy: ± 0.02 %
Materials: Stainless Steel, Epoxy, Nylon, PVC
Cable Length: 10 m
Display Type: None
Output Detail: Pulse Dry-Contact Output (-PS Models), Maximum Voltage: 5 to 24 Vdc, Maximum Current: 10 mA ac/dc, Maximum Power: 0.25 W, Relay Output: Form C (SPDT), rated 5A@120/240 Vac; Load Driving Capacity: 1150 Ω max
Output Signal: DC Pulse
Response Time: 2 sec
Switch Rating: 5 A @ 120/240 Vac
Supply Voltage: 12 to 35 Vdc
Viscosity Range: 0 to 5 cPs
Electrical Output: Amplified Square Wave
Materials, Wetted: 316 SS, Acetal Copolymer, Buna-N (NBR), EPR, FKM, PEEK, Polycarbonate
Type of Operation: Sensor Transmitter
Response Time Note: 2 s to 90% (step change in flow rate)
Media Compatibility: Liquids
Repeatability Error: 0.005
Electrical Connection: Cable
Operating Pressure, Max: 200 psi
Process Connection Size: 1/2 in
Process Connection Type: NPT Female
Volumetric Flow Rate, Max: 18.9 l/min
Volumetric Flow Rate, Min: 1.9 l/min
Material Construction Option: Visual Indicator
