Noise: 1 mVrms
Height: 19 mm
Isolation: 50 MΩ
Supply Voltage: 220 Vac
Voltage Accuracy: ±1%
Electrical Output: 500 mA, +5V
Number of Outputs: 1
Power Consumption: N/A
Supply Power Note: 115 Vac, 220 Vac (-220 suffix) or 230 Vac (-230 suffix) ±10 Vac
Frequency Input Range: 50 to 60 Hz
Isolated Analog Voltage: 1500 Vrms
Short-Circuit Protected: Foldback current limiting
Temperature Coefficient: ±0.02%
Line and Load Regulation: ±0.05%
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -25 °C
Operating Temperature Note: Maximum Case Operating Temperature Without Derating: 71°C (160°F)
Operating Temperature, Max: 71 °C
