Technical parameter：
Input power supply: Single phase AC220V, 50Hz
Motor power: 1500W
Cutting ability: Φ 60mm
Travel Y-axis: 260mm
Cutting blade specification: Φ200×1.0×Φ32mm
Cutting platform size: 225x320mm
Cutting blade rotation speed: 500-5000rpm
Cutting jig: Quick Fixture
Lateral clamping width: 225mm
Longitudinal clamping length: 150mm
Cutting method: Y-axis automatic feeding (automatic homing after cutting), manual feeding, pulse feeding (automatic homing after cutting)
Feed speed: 0-180mm/min(The adjustment step length is 0.01 mm)
Operation mode: Touch screen
Cooling method: water cooling
Equipment size: 830×810×410mm
Weight: 130KG
Main Functions and Features:
1. Touch screen control and display is adopted, which is easy to operate, clear and intuitive.
2.The visible transparent window design made of PC material makes the cutting process clear at a glance.
3.The design of double layer protective knot and safety door switch makes the cutting process safer.
4. It supports stepless speed regulation or three-gear speed regulation mode, making speed regulation more convenient.
5.There are multiple cutting modes to choose from, which can meet different cutting needs of users.
6. Multilayer filtration circulating water supply system to avoid sample surface heating during cutting and save water consumption.
7. Equipped with a quick fixture, it is faster and more convenient to install the workpiece.
8. The clamp and workbench are made of aluminum alloy and stainless steel, making them more durable.
9. Can store more than 100 sets of cutting process parameters for quick invocation
10. The emergency stop button can quickly and conveniently stop the operation, making it safer.
