- Technical Parameters:
Initial test force: 3kgf(29.42N)
Test force: 15kgf(147.1N), 30kgf(294.2N), 45kgf(441.3N)
Rocky ruler: HRA、HRB、HRC、HRD、HRE、HRF、HRG、HRH、HRK
Measuring range: HR15N, HR30N, HR45N, HR15T, HR30T, HR45T
Data output: Dial reading
Executive standard: GB/T230.1, GB/T230.2, National standard: JJG112 Verification procedure
Maximum height of the test piece: 190mm
Indenter-outer wall distance: 160mm
Power supply: AC220V+5%,50~60Hz
Dimensions (mm): 520*240*700
Host weight: Around 70Kg
Main features and features:
1. The hardness value is directly read through the dial pointer, the pointer is sensitive, and the measured result is higher than the national standard;
2. The shell is formed by a special sand-casting process. The structure is stable and not deformed, and it can work under harsh environment. The car paint has high grade and strong scratch resistance. It is still bright and new for many years.
3, test force: application, load, unloading automatically completed;
4. We have the ability to develop and design, manufacture and process our own machines. Our machines provide replacement and maintenance upgrade services for life.
Main use and scope of application:
1. Hardened steel, quenched and tempered steel, annealed steel, bearing steel, strip steel, hardened steel sheet, hard alloy, etc.
