Jumo 608201 Mechanical dial thermometer (0 ~ +120 °C)

Order code: 608201/1010-818-00-0-750-8-000-26-26-100/000

Basic type extension: Design type: 10; case size: ø 100 mm

Display range (AB): 0 to +120°C

Capillary type (FL): Without (with rigid connection)

Capillary length: Without (with rigid connection)

Process connection (PC): TF01; Temperature probe with stepped support tube

Diameter of process connection (PC): Ø 08 m

Thread type of process connection (PC):  Without thread (for TF 01 and TF 11)

Material, probe / support tube: Stainless steel (CrNi, 1.4571)

Material of process connection (PC):  Stainless steel (CrNi, 1.4571)

Insertion length, process connection (PC): 100 mm

Extra codes (TZ): Without extra code

Dial thermometers are temperature indicators for universal use. The devices come in a stainless steel case with a liquid or gas-filled measuring system.
