Karg FD023 Drying and heating chambers (5°C - 300 °C, 0.8kW)

Performance Data Temperature

Temperature range 5 °C above ambient temperature to [°C]: 300

Temperature variation at 150 °C [± K]: 2.5

Temperature fluctuation at 150 °C [± K]: 0.3

Heating-up time to 150 °C [min]: 25

Recovery time after 30 seconds door open at 150 °C [min]: 6

Air change data

Air change (approx.) at 150 °C [x/h]: 64

Electrical data

Rated Voltage [V]: 230

Power frequency [Hz]: 50 / 60

Nominal power [kW]: 0.8

Unit fuse [A]: 10

Phase (Nominal voltage) [ph]: 1~

Outer dimensions

Width net [mm]: 435

Height net [mm]: 495

Depth net [mm]: 520

Wall clearance back [mm]: 160

Wall clearance sidewise [mm]: 100

Doors

Unit doors: 1

Internal Dimensions

Width [mm]: 222

Height [mm]: 330

Depth [mm]: 300

Further Dimension

Interior volume [L]: 20

Net weight of the unit (empty) [kg]: 27

Permitted load [kg]: 25

Load per rack [kg]: 12

Environment-specific data

Energy consumption at 150 °C [Wh/h]: 300

Fixtures

Number of shelves (std./max.): 2 / 4
