Leadfluid BT103S+DT10-18 Speed-Variable Peristaltic Pump (0.0001～480ml/min, 14#, silicone tube 2m)

Flow range: 0.0001～480ml/min

Speed range: 0.1～100rpm

Speed resolution: 0.1rpm

Speed accuracy: <±0.2%

Display mode: Window 77x32mm, Monochromatic 128x32 lattice liquid crystal

Language: Switching between Chinese and English

Operation mode: Industrial mask keypad

Keypad locked: Long press direction keypay to lock, long press start andstop key to unlock

Timing function: Timing running time 0.1～999 S/Min/H/D, interval time 0.1～999 S/Min/H/D

Cycle times: 0～999（0 Infinite cycle)

Back suction angle: 0～720°

External control signal input: (1)Start /Stop: passive contact, external control input level (5~24V) (2)Reversible direction: passive contact, external control input level (5~24V) (3)Adjust speed: analog quantity 0~5V, 0~10V, 4~20mA can set.

External control signal output: (1)Start /Stop: level signal (following input voltage) (2)Reversible direction: level signal (following input voltage) (3)Speed state: analog quantity 0~5V

Communication interface: RS485, MODBUS protocol is available, DB15 external control interface

Power supply: AC100～240V, 50Hz/60Hz

Power consumption: <30W

Working environment: Temperature 0～40℃, relative humidity<80%

Dimension（L×W×H): 232x140x145mm

Drive weight: 2.9 kg

Pump head: DT10-18

Channel: 1

Tube: 14#, wall thickness 0.8～1mm, ID≤3.17mm

Per channel flow rate（ml/min）: 0.0002～82
